Performance Partitioning

For reliable fire and acoustic performance. Flexible enough for any modern workspace.

KCA Performance Partitioning System is designed to meet the practical needs of your office or light industrial space, where safety, sound control and flexibility all matter.

Strong, stylish and built for a wide range of applications, this system balances proven performance with clean, contemporary design aesthetics. Whether you’re working on a busy office layout or a technical environment with higher compliance needs, this system delivers dependable results.

Key Features

  • Fire-rated options up to 30 minutes (tested to BS476 Part 22)
  • Acoustic performance up to 43dB (Rw)
  • Solid panel, single glazed, and double glazed configurations
  • Durable, demountable, and relocatable structure
  • Prefabricated door frame kits for fast and tidy installation

This Performance Partitioning System is built on a galvanised steel stud framework with robust aluminium profiles and trims. With multiple layout options, including solid wall sections or glazed elevations, it gives designers and specifiers full flexibility to configure the system to suit any environment.

Choose between square-edged or radiused profile trims, available in a broad choice of RAL and BS colours, as well as standard satin anodised aluminium (SAA) finishes.

To elevate the system further, optional features include:

  • Integral blinds for privacy
  • Electric switchable glass
  • Glass manifestation and industrial-style glazing banding
  • Performance meets design flexibility

This Performance Partitioning System delivers fire and sound protection where it’s needed, without compromising on style. From client facing office spaces to technical rooms or meeting areas, this Performance Partitioning System helps you create environments that feel safe, comfortable and modern.

System Specifications

Dimensions

  • Max height – 3000mm
  • Max module width – 1200mm

Acoustics

  • Solid plasterboard – Up to 43dB (Rw)
  • Single glazed – Up to 34dB (Rw)
  • Double glazed – Up to 40dB (Rw)

Fire Rating

  • Tested to BS476-22:1987
  • Solid screen – 30/0 minutes (integrity/insulation)
  • Glazed screen – 30/0 minutes (integrity/insulation)
  • Timber door (aluminium frame) – 30/0 minutes integrity/insulation

Structural Performance

  • Up to medium duty
  • Contact us for details

Screen Options

  • Glazed
  • Plasterboard (BS EN 520 Type A)
  • Chipboard

Glazing Options

  • Full & mid height
  • Single centre glazed
  • Offset single glazed
  • Double glazed

Profile Finishes

  • Square or radiused edge
  • Powder coated to any RAL or BAS colour
  • Satin anodised aluminium – Grade AA5 (SAA)

Glazing Finishes

  • Manifestation & graphics
  • Integrated blinds (double glazed)
  • Industrial style banding

Door Options

  • Prefabricated door frame kit
  • Single and double leaf
  • Acoustic glass doors
  • 44mm solid timber – veneered, laminate or primed finish, with vision panel options

Precise performance will be influenced by wall to window/door ratios along with other variables such as glass thickness and type. Contact us for details.

Need a quote or more information?

We supply partitioning systems to businesses and trade professionals across London, the South East, and the UK. Whether you’re working on a new build or a refurbishment project, our expert team can guide you through the options.
